LG Transparent OLED Signage

Discuss a transparent digital signage project. Enquire for your application across Jharkhand and West Bengal; model and installation scope confirmed per requirement.

Product enquiry on WhatsApp | Call 87952 51777 | Request an AV quotation

Category:

Description

Discuss a transparent digital signage project

For a retail display, exhibition or reception feature, share what should remain visible behind the screen and the content you intend to show. Include lighting, background, viewing angles and operating hours. Confirm the exact model and installation design rather than treating all transparent OLED displays as interchangeable.

AV enquiries across Jharkhand and West Bengal

Enquiries are welcome from individuals, homes, businesses, education, healthcare, hospitality, retail, industry, NGOs and government across both entire states. Share quantity, intended use, budget, timeline and delivery PIN code. Exact model specifications, sourcing, availability, compatibility, accessories, delivery and installation feasibility are confirmed for each requirement.

Product enquiry on WhatsApp | Call 87952 51777 | Request an AV quotation

Explore our AV product range

Key Features

  • Brightness(Typ.): 400nit (APL 25%, Without Glass)
  • Transparency(Typ.) : 38%
  • Bezel : 7.9 mm (T/B/L), 121.7 mm (B)
  • Interface : HDMI/DP/USB(2)/ RS232C/ RJ45/ Audio/ IR

All Spec

PANEL

  • Screen Size

    139 cm (55)

  • Panel Technology

    OLED

  • Back Light Type

    OLED

  • Aspect Ratio

    16:9

  • Native Resolution

    1920 x 1080 (FHD)

  • Refresh Rate

    120Hz

  • Brightness

    150/400nit (APL 100%/25%, without Glass)

  • Contrast Ratio

    150,000:1

  • Dynamic CR

    NO

  • Color Gamut

    BT709 120%

  • Viewing Angle (H x V)

    178º x 178º

  • Color Depth (Number of Colors)

    1.07 Billion colors

  • Response Time

    1ms (G to G), 8ms (MPRT)

  • Surface Treatment (Haze)

    Haze 3% (SET)

  • Life time

    30,000Hrs (Typ.)

  • Operation Hours (Hours/Day)

    18/7 (Moving Content Only)

  • Portait / Landscape

    YES / YES

  • Transparency

    38% (SET)

  • QWP (Quarter Wave Plate)

    N/A

CONNECTIVITY

  • HDMI In

    YES (1ea)

  • HDMI In (HDCP Ver.)

    1.4

  • DP In

    YES (HDCP 1.3)

  • DVI-D In

    NO

  • RGB In

    NO

  • Audio In

    NO

  • RS232C In

    YES

  • RJ45(LAN) In

    YES (1ea)

  • IR In

    YES

  • USB In

    USB2.0 Type A (2ea)

  • HDMI Out

    NO

  • DP Out

    YES

  • Audio Out

    YES

  • Touch USB

    NO

  • External Speaker Out

    NO

  • RS232C Out

    YES

  • RJ45(LAN) Out

    YES

  • IR Out

    YES (Sharing RS232C Out)

  • Daisy Chain

    Input : HDMI, DP / Output : DP

MECHANICAL SPECIFICATION

  • Bezel Color

    Transparent

  • Bezel Width

    T/R/L/B : 7.9/7.9/7.9/121.7mm

  • Weight (Head)

    11.7Kg (Head) 3.4Kg (Signage Box)

  • Packed Weight

    23.2Kg

  • Monitor Dimensions (W x H x D)

    1225.5 x 810.1 x 6.6mm (Head) 782.8 x 238.4 x 34.7mm (Signage Box)

  • Monitor Dimension with Stand (W x H x D)

    N/A

  • Handle

    NO

  • VESA Standard Mount Interface

    N/A

  • Carton Dimensions (W x H x D)

    1345 x 920 x 207mm

  • Weight (Head+Stand)

    N/A

PROTECTION GLASS

  • Thickness

    3mm

  • Degree of Protection

    N/A

  • Tempered / Chemical strengthening

    Chemical strengthening

  • Anti-Reflective

    YES

  • Infrared – Resistance (IR)

    N/A

  • Shatter-Proof

    YES

FEATURE – HARDWARE

  • Internal Memory (eMMC)

    16GB

  • Wi-Fi/BT (Built-in)

    NO

  • Temperature Sensor

    YES

  • Auto Brightness Sensor

    NO

  • Pixel Sensor

    NO

  • Proximity Sensor

    NO

  • Current Sensor

    NO

  • BLU Sensor

    NO

  • Humidity Sensor

    NO

  • Acceleration(Gyro) Sensor

    NO

  • Power Indicator

    NO

  • Local Key Operation

    NO

  • FAN (Built-in)

    NO

FEATURE – SOFTWARE

  • OS Ver. (webOS)

    webOS 4.0

  • Local Contents Scheduling

    YES

  • Group Manager

    YES

  • USB Plug & Play

    YES

  • Fail Over

    YES

  • Booting Logo Image

    NO

  • No Signal Image

    NO

  • RS232C Sync

    YES

  • Local Network Sync

    YES

  • Backlight Sync

    NO

  • PIP

    NO

  • PBP

    NO

  • Screen Share

    NO

  • Video Tag

    YES (4 Video Tag)

  • Play Via URL

    NO

  • Screen Rotation

    YES

  • External Input Rotation

    YES

  • Gapless Playback

    YES

  • Tile Mode Setting

    YES

  • Setting Data Cloning

    YES

  • SNMP

    YES

  • ISM Method

    YES

  • Auto Set ID

    YES

  • Status Mailing

    YES

  • Control Manager

    YES

  • Cisco Certification

    NO

  • Crestron Connected

    YES

  • Smart Energy Saving

    NO

  • PM mode

    YES

  • Wake on LAN

    YES

  • Network Ready

    NO

  • BEACON

    NO

  • HDMI-CEC

    YES

  • SI Server Setting

    YES

  • webRTC

    NO

  • Pro:Idiom

    YES

  • Brightness Compensation

    NO

  • W/B Setting by Grey scale

    NO

  • Scan Inversion

    NO

ENVIRONMENT CONDITIONS

  • Operation Temperature

    0 °C to 40 °C

  • Operation Humidity

    10 % to 80 %

POWER

  • Power Supply

    AC 100-240V~, 50/60Hz

  • Power Type

    Built-in Power

POWER CONSUMPTION

  • BTU (British Thermal Unit)

    853.03 BTU/Hr(Typ.), 955.39 BTU/Hr(Max.)

  • Smart Energy Saving (70%)

    N/A

  • DPM

    0.5W

  • Power off

    0.5W

  • Max.

    280W

  • Typ.

    171W (IEC 62087)

SOUND

  • Speaker (Built-in)

    NO

CERTIFICATION

  • Safety

    CB / NRTL

  • EMC

    FCC Class “A” / CE / KC

  • ERP / Energy Star

    YES / NO

  • ePEAT(US only)

    NO

OPS COMPATIBILITY

  • OPS Type compatible

    N/A

  • OPS Power Built-in

    N/A

SOFTWARE COMPATIBILITY

  • SuperSign CMS

    YES

  • SuperSign Control+

    YES

  • SuperSign WB

    YES

  • SuperSign Cloud

    NO

  • Mobile CMS

    YES

  • Connected Care

    YES

LANGUAGE

  • OSD

    English, French, German, Spanish, Italian, Korean, Chinese(Simplified), Chinese(Original), Portugues(Brazil), Swedish, Finnish, Norwegian, Danish, Russian, Japanese, Portugues(Europe), Dutch, Czech, Greek, Arabic

ACCESSORY

  • Basic

    Remote Controller(include battery 2ea), Power Cord, QSG, IR receiver, Regulation Book, Phone to RS232C Gender, MCX/Harness Cables(3000mmx4ea/3000mmx2ea for connection between panel and Signage Box), DP Cable(2M), LAN Cable(1.5M), RS232 Cable(4P-4P,1.5M), LC Cable(VLC,3M), Screw(M4xL22,12ea / M4 Nut,12ea / M3xL5.5,8ea / M3xL3.5,20ea), Shield Cover Assy’, Rubber Damper 4ea, MCX cable Holder 4ea

  • Optional

    Stand (ACC-S-EW5F, 2 Pole), Tiling (ACC-V-EW5F)

SPECIAL FEATURE

  • Overlay Touch Compatibility

    N/A

  • Smart Calibration

    N/A

  • Tilt (Face up)

    N/A

  • Tilt (Face down)

    N/A

  • IP Rating

    N/A

  • Conformal Coating (Power Board)

    N/A

  • Power Protection

    N/A

  • Direct Sunlight

    N/A

DEDICATED FEATURE – TOUCH

  • Available Object Size for Touch

    N/A

  • Response Time (‘Paint’ app on Windows 10 PC)

    N/A

  • Accuracy (Typ.)

    N/A

  • Interface

    N/A

  • Protection Glass Thickness

    N/A

  • Protection Glass Transmission

    N/A

  • Operating System Support

    N/A

  • Multi Touch Point

    N/A
